Loa FDB PLA410

Mã sản phẩm: #PLA410

Thương hiệu: FDB

2x10" 3-way line array system

Giá liên hệ

Hotline / Zalo: 0911.253.454
Địa chỉ: 50 Trần Quý Cáp, P. Thạch Thang, Q. Thanh Khê, TP. Đà Nẵng.

Để lại thông tin tư vấn?

Thông tin Sản phẩm

DESCRIPTION

PLA410 is a two-way, all-weather line array speaker, designed with priority given to waterproof, dustproof, windproof, anti-uv aging, and five-layer grille design of different materials. The product meets the IP66 standard, all hanging parts and connecting parts are made of stainless steel or aluminum, features low-distortion mid-bass unit and mid-high coaxial driver with special waveguide and horn, accurate coverage, three-point hanging system, ensure safety. Unit configuration:2x10" high efficiency mid-bass unit, 1x1.4" exit throat 90mm voice coil neodymium MF driver and 44mm HF driver coaxial neodymium unit. The cabinet is made of polymer composite material through a special process.

FEATURES

●Product parameters have been entered into EASE loudspeaker database
●Pass IP66 testing
●Polymer composite material mold forming box, five layers of waterproof, dustproof composite grille, strong weather resistance
●Passive way, simple operation, save amplifiers
●Can be matched with PLA212B
●Applications: outdoor fixed installation

SPECIFICATIONS

MODEL	PLA410
FREQUENCY RESPONSE(-3dB)	70Hz-18KHz
FREQUENCY RESPONSE(-10dB)	65Hz-20KHz
DRIVERS	2×10"(250mm)/3"voice coil LF
	1×1.4"(36mm)/3.5"voice coil MF
	1×1.4"(36mm)/1.7"voice coil HF
RATED POWER	500W RMS,2000W peak
SENSITIVITY	101dB 1watt/1meter
MAXIMUM SPL	128dB continuous,134dB peak
IMPEDANCE	8 ohms nominal
DISPERSION(-6dB)	Horizontal coverage: 90°
	Vertical coverage: Varies, depending on
	array length and configuration
CROSSOVER FREQUENCIES	700Hz, 6KHz passive
INPUT CONNECTORS	2×Speakon NL4
PACKAGE SIZE	550mm×396mm×770mm
NET WEIGHT	23 kg/pc
GROSS WEIGHT	27 kg/pc
