Loa FDB U115VI / U115AVI

Mã sản phẩm: #U115VI / U115AVI

Thương hiệu: FDB

1x15 2 way loudspeaker system 1x15 2 way active loudspeaker system

Giá liên hệ

Hotline / Zalo: 0911.253.454
Địa chỉ: 50 Trần Quý Cáp, P. Thạch Thang, Q. Thanh Khê, TP. Đà Nẵng.

Để lại thông tin tư vấn?

Thông tin Sản phẩm

DESCRIPTION

The U115VI is a 15" two way full range speaker with bright and powerful sound. Unit configuration: 1x15" high efficiency mid-bass unit, 1x1.4" exit throat 75mm composite diaphragm HF driver with 90°×40° rotatable horn. The cabinet is made of multilayer composite plywood with wear-resistant polyurea paint. U115AVI is an active speaker with two channels and DSP digital amplfier.

FEATURES

●Product parameters have been entered into EASE loudspeaker database
●High quality unit configuration, high strength plywood housing
●Multi-hanging points and support, easy and quick operation
●Applications: large-scale indoor sound reinforcement, multifunction halls, high-end hotel clubs, touring, band reinforcement and monitor speaker

SPECIFICATIONS

MODEL	U115VI	U115AVI
FREQUENCY RESPONSE(-3dB)	45Hz-18kHz	45Hz-18kHz
FREQUENCY RESPONSE(-10dB)	40 Hz-20kHz	40 Hz-20kHz
DRIVERS	1×15"(385mm)/3"voice coil LF	1×15"(385mm)/2.5"voice coil LF
	1×1.4"(36mm)/3"voice coil HF	1×1"(25mm)/1.4"voice coil HF
RATED POWER	400W RMS,1600W peak	500W/4Ω+50W/8Ω
SENSITIVITY	98dB 1watt/1meter	--
MAXIMUM SPL	124dB continuous,130dB peak	124dB continuous,130dB peak
IMPEDANCE	8 ohms nominal	--
DISPERSION(-6dB)	90°×40°	90°×40°
CROSSOVER FREQUENCIES	1.5kHz passive	--
INPUT CONNECTORS	2×Speakon NL4	INPUT TYPE:Balanced Differential line
PACKAGE SIZE	580mm×560mm×820mm	580mm×560mm×820mm
NET WEIGHT	30 kg/pc	25 kg/pc
GROSS WEIGHT	35 kg/pc	30 kg/pc
