Loa FDB U112VI/U112AVI

Mã sản phẩm: #U112VI/U112AVI

Thương hiệu: FDB

1x12" 2-way Loudspeaker System/1x12" 2-way Active Loudspeaker System

Giá liên hệ

Hotline / Zalo:  0911.253.454
Địa chỉ: 50 Trần Quý Cáp, P. Thạch Thang, Q. Thanh Khê, TP. Đà Nẵng.

Để lại thông tin tư vấn?

DESCRIPTION

The U112VI is a 12" two way full range speaker with clear and bright sound. Unit configuration: 1x12" high efficiency mid-bass unit, 1x1" exit throat 44mm poliyimide diaphragm HF driver with 90°×40° rotatable horn.  The cabinet is made of multilayer composite plywood with wear-resistant polyurea paint. U112AVI is an active speaker with two channels and DSP digital amplfier.


FEATURES

●High quality unit configuration, high strength plywood housing
●Multi-hanging points and support, easy and quick operation
●Applications: large-scale indoor sound reinforcement, multifunction halls, high-end hotel clubs, touring, band reinforcement and monitor speaker

SPECIFICATIONS

MODEL U112VI U112AVI
FREQUENCY RESPONSE(-3dB) 50Hz-18kHz 50Hz-18kHz
FREQUENCY RESPONSE(-10dB) 45 Hz-20kHz 45 Hz-20kHz
DRIVERS 1×12"(300mm)/3"voice coil LF    1×12"(300mm)/2.5"voice coil LF
  1×1"(25mm)/1.7"voice coil  HF                               1×1"(25mm)/1.4"voice coil  HF
RATED POWER 300W RMS,1200W peak 500W/4Ω+50W/8Ω
SENSITIVITY 97dB  1watt/1meter --
MAXIMUM SPL 122dB continuous,128dB peak 122dB continuous,128dB peak
IMPEDANCE 8 ohms nominal --
DISPERSION(-6dB) 90°×40° 90°x40°
CROSSOVER FREQUENCIES 2kHz passive  --
INPUT CONNECTORS 2×Speakon NL4 INPUT TYPE: Balanced Differential line
PACKAGE SIZE 490mm×470mm×730mm 490mm×470mm×730mm
NET WEIGHT 21 kg/pc 19 kg/pc
GROSS WEIGHT 25 kg/pc 23 kg/pc























DOWNLOAD

U112VI & U112AVI-2023.pdf
